Model 311 GII Fire Attack™ System for EC145 C2


Part Number: 311-000001-001

Aircraft Models: Airbus - BK117

  • In stock

Key Features

  • FAA certified for day/night VFR
  • Cockpit controlled selectable drop patterns
  • Increased safety with automatic emergency door release in the event of aircraft power loss
  • Lightweight composite construction
  • Flexible Bladder for Foam storage integrated into the Main Tank assy
  • 5” Hover Pump assy fills tank in 35 seconds

Key Benefits

  • Belly Tank allows for operation in urban interface areas
  • Fly 50% faster than when using buckets
  • Drop door system offers fast and complete release of the load
  • Well ventilated tank provides steady & uninterrupted water drop
  • 24 hour firefighting possible with day/night VFR approval
  • Quickly reconfigured with installation/removal in 30 minutes

Approvals

Approval type Authority Reference number Aircraft approved Description
STC FAA - USA SR02514SE EC145(BK117C2)

OEM Cross References

N/A

External Warning

N/A

Prerequisite

N/A

Compatible With

N/A

Not Compatible With

N/A

Flight Restrictions

VNE 135 KIAS

Installation Time

N/A

Dimensions And Weight

  • Length: N/A
  • Width: N/A
  • Weight Display: 445.6 lbs / 202 kg

Load Capacity And Volume

  • Volume: 260 gal / 984 L
  • Load Capacity: N/A

Technical Documentation

N/A

Downloads

N/A
