H145 Quick Release Heli-Utility-Basket™ - LH

Mission Equipment
Part Number: D117-1044-011
Aircraft Models: Airbus - EC145

Price:
The DART Quick Release Heli-Utility-Basket™ features a quick release mounting system that enables the operator to remove and install the basket quickly, without tools. The basket is constructed of corrosion-resistant stainless steel, coated with a high-gloss, scratch-resistant white finish. Enhanced safety with a simple self-locking handle that assures lid closure and secures cargo during flight. Ease of use with gas spring to assist when opening and closing the lid. ... Read more
The DART Quick Release Heli-Utility-Basket™ features a quick release mounting system that enables the operator to remove and install the basket quickly, without tools. The basket is constructed of corrosion-resistant stainless steel, coated with a high-gloss, scratch-resistant white finish. Enhanced safety with a simple self-locking handle that assures lid closure and secures cargo during flight. Ease of use with gas spring to assist when opening and closing the lid. Support beams are also equiped with quick release hardware for tool-less removal of 97% of kit weight in minutes. *Weight capacity of 200 lbs. Includes basket with stainless steel lid, automatic lid opener and mounting kit. Not compatible with floats. Cannot be installed with RH basket (one side only). Read less

Description

The DART Quick Release Heli-Utility-Basket™ features a quick release mounting system that enables the operator to remove and install the basket quickly, without tools. The basket is constructed of corrosion-resistant stainless steel, coated with a high-gloss, scratch-resistant white finish. Enhanced safety with a simple self-locking handle that assures lid closure and secures cargo during flight. Ease of use with gas spring to assist when opening and closing the lid. Support beams are also equiped with quick release hardware for tool-less removal of 97% of kit weight in minutes. *Weight capacity of 200 lbs. Includes basket with stainless steel lid, automatic lid opener and mounting kit. Not compatible with floats. Cannot be installed with RH basket (one side only).

Key Features

  • Self-locking handle
  • Gas spring assists with closing/opening and keeps lid closed/opened
  • Durable scratch resistant finish
  • Innovative quick release mounting system
  • Heavy duty lid doubles as a step or walkway for maintenance
  • Flat bottom design accommodates more types of cargo
  • Carrying handles
  • Support beams easily removed without tools

Key Benefits

  • Basket can be installed/removed by 1 person in less than 1 minute without the use of tools (after initial installation)
  • 97% of kit weight can be removed in minutes
  • Can carry up to 200 lbs of cargo externally
  • Corrosion-resistant stainless steel construction
  • Allows unobstructed passenger egress
  • Fixed provisions also available separately for easy transfer

Approvals

Approval type Authority Reference number Aircraft approved Description
STC FAA - USA SR02578SE EC145(BK117C2)/EC145T2 Installation of Heli-Utility-Basket
STC EASA - Europe 10065008 EC145(BK117C2)/EC145T2 Installation of Heli-Utility-Basket

OEM Cross References

N/A

External Warning

N/A

Prerequisite

N/A

Compatible With

N/A

Not Compatible With

N/A

Flight Restrictions

VNE restricted to 110 kias

Installation Time

4-6 hrs

Dimensions And Weight

  • Length: 94.5" / 2.4m
  • Width: 23.5" / 0.60m
  • Weight Display: 134.0 lbs / 60.8 kg

Load Capacity And Volume

  • Volume: 16.77 ft3 / 0.475m3
  • Load Capacity: 200 lbs / 90.7 kg

Technical Documentation

N/A

Downloads

N/A
