EC120 Emergency Float System (LH Pilot collective mounted inflation mechanism)

Mission Equipment
Part Number: 20498-103
Aircraft Models: Airbus - EC120

Price:
The Airbus EC120B Emergency Float System is the only float system certified for take off after water landing for the Airbus EC120. The system is compatible with ground handling wheels and the float bags can be removed within a matter of minutes. The mechanical valve system has no squibs or electrical requirements. The cylinder valve assemblies and floats are available as exchange items, thereby reducing maintenance and down time. All float chambers come standard with ... Read more
The Airbus EC120B Emergency Float System is the only float system certified for take off after water landing for the Airbus EC120. The system is compatible with ground handling wheels and the float bags can be removed within a matter of minutes. The mechanical valve system has no squibs or electrical requirements. The cylinder valve assemblies and floats are available as exchange items, thereby reducing maintenance and down time. All float chambers come standard with field replaceable pressure relief valves and inflation valves. The float bags are on-condition and do not have to be returned to the factory for recertification. Factory recertification of the system is available for customers who desire OEM services. Annual inspection of float bags, as compared with 6 month inspection required in some competitors' products lowers ongoing maintenance costs of the system. This system is approximately 20 lbs lighter than the OEM supplied system. *Kit includes LH & RH cylindrical floats. LH Pilot collective mounted inflation mechanism. Price is for complete float system. Read less

Description

The Airbus EC120B Emergency Float System is the only float system certified for take off after water landing for the Airbus EC120. The system is compatible with ground handling wheels and the float bags can be removed within a matter of minutes. The mechanical valve system has no squibs or electrical requirements. The cylinder valve assemblies and floats are available as exchange items, thereby reducing maintenance and down time. All float chambers come standard with field replaceable pressure relief valves and inflation valves. The float bags are on-condition and do not have to be returned to the factory for recertification. Factory recertification of the system is available for customers who desire OEM services. Annual inspection of float bags, as compared with 6 month inspection required in some competitors' products lowers ongoing maintenance costs of the system. This system is approximately 20 lbs lighter than the OEM supplied system. *Kit includes LH & RH cylindrical floats. LH Pilot collective mounted inflation mechanism. Price is for complete float system.

Key Features

  • Includes 2 cylindrical floats
  • Floats removed in minutes
  • Inspections at 18 months (instead of 12)
  • Exchange program available

Key Benefits

  • Reduced installation time vs competitor
  • Lower maintenance costs due to longer inspection cycles
  • Certified for take-off after water landing
  • Lighter weight than competitor

Approvals

Approval type Authority Reference number Aircraft approved Description
STC EASA - Europe EASA.IM.R.S.01013 EC120B Cylindrical Emergency Float System
STC TCCA - Canada SH99-218 EC120B Cylindrical Emergency Float System
STC FAA - USA SR00780LA EC120B Cylindrical Emergency Float System

OEM Cross References

N/A

External Warning

N/A

Prerequisite

N/A

Compatible With

N/A

Not Compatible With

N/A

Flight Restrictions

Max. Airspeed of Inflation: 75 KIAS Max. Airspeed with Floats Inflated: 95 KIAS

Installation Time

30 hrs

Dimensions And Weight

  • Length: N/A
  • Width: N/A
  • Weight Display: 100.00 lbs / 45.36 kg

Load Capacity And Volume

  • Volume: N/A
  • Load Capacity: N/A

Technical Documentation
