BK117 Quick Release Heli-Utility-Basket™ Fits LH or RH
Part Number: D117-837-011
Aircraft Models: Airbus - BK117
In stock
The DART Quick Release Heli-Utility-Basket™ features quick release pins that enable the operator to remove and install the basket quickly, without tools. The basket is constructed of corrosion-resistant stainless steel, coated with a high-gloss, scratch-resistant white finish. Enhanced safety with a simple self-locking handle that assures lid closure and secures cargo during flight. Ease of use with gas spring to assist when opening and closing the lid. The basket features a flat heavy duty stainless steel lid that doubles as a step or as a work platform and is attached using a robust hinge system.
*Baskets comes with automatic lid opener and mounting provisions. Optional prop arm available by special order (please specify on order). Category A and IFR certified. Not compatible with BK117C2. Price is per side.
Couldn't load pickup availability
Key Features
Self-locking handle
Gas spring assists with closing/opening and keeps lid closed/opened
Optional prop arm kit available
Durable scratch resistant finish
Quick release pip pin attachment
Heavy duty lid doubles as a step or walkway for maintenance
Flat bottom design accommodates more types of cargo
Key Benefits
Easy to re-install and remove in minutes
Corrosion-resistant stainless steel construction
Installs on low and high gear
Approved to be flown on left-hand or right-hand side
No VNE restriction
Installs using existing aircraft hard points
Does not impede access to the cargo doors
Allows unobstructed passenger egress
Fixed provisions also available separately for easy transfer
Maximum take-off and landing gross mass is reduced by 132 Ib/60 kg for Category A operations.
Category A Segment, OEI Climb Performance must be adjusted as follows: Subtract 2 ft/100 ft
Installation Time
Contact Tech Support
Dimensions And Weight
Length: 96" / 2.4m
Width: 25" / 0.64m
Weight Display: 120.00 lbs / 54.40 kg
Load Capacity And Volume
Volume: 18.2 ft3 / 0.51 m3
Load Capacity: 210 lbs / 95.3 kg Distributed cargo load
