412 OEM Replacement Emergency Float Aft


Part Number: 20714-100

Aircraft Models: Bell - 412

  • A few left in stock!
The Bell 412 uses 6 floats (2 forward, 2 middle and 2 Aft). The right and left forward and middle floats (20715) are interchangeable and the right and left Aft floats (20714) are interchangeable. The forward or middle floats consists of 4 separate air-holding chambers. The chambers are separated by bulkheads made of the same urethane coated nylon as the tube to minimize the loss of buoyancy in the event of puncture or tear. Each chamber contains an inlet check valve for inflation by the cylinder/valve assembly, a topping valve for manual inflation and a pressure relief valve (PRV) to prevent over-pressurization. *Replaces Bell Aft floats (412-050-013-119). Approved for intermix with Bell floats. Price is per float.

Key Features

  • Exchange program available

Key Benefits

  • Economic option for OEM float system
  • Reduced maintenance cost (longer maintenance intervals)

Approvals

Approval type Authority Reference number Aircraft approved Description
STC EASA - Europe 10061095 212/412/412EP Installation of Emergency Float Assemblies
STC TCCA - Canada SH07-34 412/412EP Replacement Emergency Floats
STC FAA - USA SR01298LA 412/412EP Replacement Emergency Floats

OEM Cross References

N/A

External Warning

N/A

Prerequisite

N/A

Compatible With

N/A

Not Compatible With

N/A

Flight Restrictions

N/A

Installation Time

2 hrs

Dimensions And Weight

  • Length: N/A
  • Width: N/A
  • Weight Display: 21 lbs / 9.55 kg

Load Capacity And Volume

  • Volume: N/A
  • Load Capacity: N/A

Technical Documentation

Login

Downloads

N/A
