Description
The Avionics Console mounts onto the instrument panel pedestal to allow installation of additional avionics units.
*Comes pre-assembled, mounts onto the instrument panel pedestal, allows installation of additional avionics units. High slope console provides more vertical than horizontal space for avionics installation. Radio depth cannot exceed 14.5" measured from the face plate when installing on the lower portion of the console. Max static load of 60 lbs or 3 lbs per inch of face plate length.
Key Features
- Modern look
- Easy installation
- More space
- Better visibility
Key Benefits
N/A
Approvals
| Approval type | Authority | Reference number | Aircraft approved | Description |
|---|---|---|---|---|
| STC | DGCA - Mexico | IA-485/2018 | 206A/206B/206L/206L1/206L3/206L4/407 | Shroud Module |
| STC | EASA - Europe | RC 1180 | 206A/206B/206L/206L1/206L3/206L4/407 | Avionic Console |
| STC | TCCA - Canada | SH89-28 | 206A/B/206L/206L1/206L3/206L4/407 | Shroud Module |
| STC | FAA - USA | SR00551NY | 206A/206B/206L/206L1/206L3/206L4/407 | Shroud Module |
